打印方式

HDP染色升華/樹脂熱轉印

分辨率

300 dpi (11.8 dots/mm)

色彩

16.7萬種/256種色彩每像素

色帶選擇

全色帶(Y,M,C)* 全色帶 + 黑色 （Y,M,C,K） * 全色帶 + 2黑色（Y,M,C,K,K）*

覆膜選擇

透明膜(1,250 prints)

Overlaminate Options

PolyGuard Overlaminate, 1.0 mil and .6 mil thick
All overlaminates available in clear, holographic globe design or custom holographic design.

打印速度

85 seconds per card / 42 cards per hour (YMCKK with transfer)*
93 seconds per card / 38 cards per hour (YMCKK/lamination)*

打印尺寸

CR-100 (3.88"L x 2.63"W / 98.5mmL x 67mmW)

打印區域

Over-the-edge

卡片厚度

.030" (30 mil) only

卡片類型

ABS, PVC, PET, PETG, and mag stripe cards

進卡槽容量

100 cards (.030" / .762mm)

出卡槽容量

100 cards (.030" / .762mm)

內存

8MB RAM

顯示

用戶界面友好，4行LCD顯示

驅動環境

Windows? 2000/XP

接口

USB 1.1

工作溫度

65° to 80° F / 18° to 27° C

工作濕度

20-80% 不冷結

機器規格

Printer: 13”H x 22.5”W x 10.75”D / 330mmH x 570mmW x 275mmD
Printer + Lam: 13”H x 35”W x 10.75”D / 330mmH x 890mmW x 275mmD
Lam Module: 10”H x 12.5”W x 10.25”D / 255mmH x 318mmW x 260mmD

機器重量

HDP600 CR100: 39 lbs. / 17.7 kg
HDP600 CR100 + Lam: 58 lbs. / 26.4 kg
Lam Module: 19 lbs. / 8.7 kg

Agency Listings

UL 60950, CSA C2.2 No. 60950, CB report (EN 60950), CE mark
Emissions: FCC Part15 Class B, EN 55022: 1998 Class B, CRC c1374, ITS EMC mark, EN 61000-3-2: 2000, EN 61000-3-2: 1995, EN 55024: 1998, CE mark

工作電壓

100-240 VAC, 3.3A

頻率

50 Hz / 60 Hz

Fargo 安全耗材

Fargo Card Printer/Encoders require highly specialized media to function properly. To maximize printed card quality and durability, printhead life and printer/encoder reliability, use only Fargo Secure Materials. Fargo warranties are void, where not prohibited by law, when non-Fargo Secure Materials are used.

編碼選項

ISO Magnetic Stripe Encoding Module, dual high- and low-coercivity, Tracks 1, 2, and 3 (available soon)

其他可選

Printer Cleaning Kit
Card Lamination Module
External Print Server (Windows only; parallel port only; required for stand-alone networking of printer/encoders)
Ethernet with internal print server
ISO Magnetic Stripe Encoding Module (available soon)
